Ball Screw Tables

Reliable and precise positioning

Ball-screw stages convert rotary motor input into precise linear motion through a recirculating-ball screw and nut. The mechanical advantage of the screw multiplies thrust, increases reliability and precision, and survives high-payload duty cycles. IKO's ball-screw table family covers strokes from 10 millimeters in compact precision modules up to 1,400 millimeters in heavy-duty TU stages — ten series in total spanning instrumentation, machine tool, and inspection applications.

High thrust, holds position. Ball-screw mechanical advantage drives heavy payloads with modest motor sizing. Static load holding without brake or holding torque.
Ten series for a variety of applications. Compact precision (PD…S, TM), modular utility (TS/CT, TU), and heavy-duty (TSL…M, TSLH…M, TX…M) — selectable by stroke, payload, and integration depth.
Pre-engineered as a system. Screw, bearing, frame, and end blocks ship as a tuned assembly. Mount the motor, wire the controller, run the stage.

Series

Series
PD...S
Compact precision ball-screw stage with ground screw and 1 mm lead for sub-micron-resolution micro-positioning in instrumentation.
- Ground screw, 1 mm lead
- C-Lube maintenance-free
- Aluminum-alloy frame
- Short stroke (10-20 mm)
Stroke range
10 – 20 mm
Max speed
50 mm/s
Max payload
5 kg
Screw lead
1 mm
Catalog View products
Series
TC...EB
Mid-travel ball-screw stage with end-block-bearing geometry for stiff, repeatable positioning across 200 to 800 mm stroke.
- End-block-bearing geometry
- Stroke 200-800 mm
- Speed to 1,100 mm/s
- Horizontal payload to 36 kg
Stroke range
200 – 800 mm
Max speed
1,100 mm/s
Horizontal payload
12 – 36 kg
Catalog View products
Series
TE...B
End-block ball-screw stage with extended stroke and higher-velocity option for mid-payload precision motion.
- End-block geometry
- Stroke 410-800 mm
- Speed to 1,860 mm/s
- Horizontal payload to 36 kg
Stroke range
410 – 800 mm
Max speed
1,860 mm/s
Horizontal payload
12 – 36 kg
Catalog View products
Series
TM
Miniature ball-screw stage for compact instrumentation with small-payload, short-stroke precision motion.
- Stroke 50-60 mm
- Sub-2 kg payload
- Compact instrumentation form
- Ball-screw drive
Stroke range
50 – 60 mm
Max speed
75 mm/s
Horizontal payload
0.7 – 1.5 kg
Catalog View products
Series
TS_CT
Modular short-stroke ball-screw stage with broad payload envelope — instrumentation-scale stroke at industrial-scale carry mass.
- Short stroke (7-125 mm)
- Payload 4.3-310 kg
- 13 product variants
- Modular form factor
Stroke range
7 – 125 mm
Max speed
250 mm/s
Horizontal payload
4.3 – 310 kg
Catalog View products
Series
TSL...M
Heavy-payload ball-screw stage in the TSL family with strokes to 1 meter and horizontal carry capacity up to 226 kg.
- Stroke 300-1,000 mm
- Payload to 226 kg horizontal
- Speed to 1,000 mm/s
- Heavy-duty class
Stroke range
300 – 1,000 mm
Max speed
1,000 mm/s
Horizontal payload
46 – 226 kg
Catalog View products
Series
TSLH...M
Highest-payload ball-screw stage in the TSL family with horizontal carry capacity up to 536 kg in stroke ranges from 300 to 800 mm.
- Payload to 536 kg horizontal
- Stroke 300-800 mm
- Speed 448-500 mm/s
- Heavy-duty class
Stroke range
300 – 800 mm
Max speed
500 mm/s
Horizontal payload
135 – 536 kg
Catalog View products
Series
TU
Workhorse ball-screw stage — the largest TU family with strokes up to 1.4 meters and 28 product variants for mid-payload precision motion.
- 28 products in the family
- Stroke 100-1,400 mm
- Speed to 1,860 mm/s
- Payload to 154 kg
Stroke range
100 – 1,400 mm
Max speed
1,860 mm/s
Horizontal payload
11 – 154 kg
Catalog View products
Series
TX...M
High-payload ball-screw stage for heavy-duty automation — carry mass up to 536 kg across stroke ranges from 300 to 800 mm.
- Payload to 536 kg horizontal
- Stroke 300-800 mm
- Speed 448-500 mm/s
- Heavy-duty automation
Stroke range
300 – 800 mm
Max speed
500 mm/s
Horizontal payload
254 – 536 kg
Catalog View products
