Specialized Positioning Tables and Stages

Compact motion, integrated stages

Precision positioning tables package a guide, a driving mechanism, and a frame into a single mountable module — sized for benchtop and tool-room applications where space, accuracy, and repeatability matter more than stroke length. IKO's six series cover rotational stages (AT, SA…DE, SK...W), short-stroke X/Y (AM, TZ), and timing-belt-driven travel (TSLB), each with the bearing and feedback hardware sized to the duty cycle.

Stage-grade accuracy. Tight parallelism, attitude, and straightness baked in at assembly — preserved across the operating envelope, not field-tuned.
Six motion geometries. Linear (AM, TSLB, TZ) and rotational (AT, SA…DE, SK...W) — pick the geometry that fits the work, not the other way around.
Stack for X-Y-θ. Modular form factors stack cleanly for multi-axis fixturing without bespoke machining or stacked baseplates.

Series

Series
AM
Compact ball-screw-driven positioning table for benchtop and tool-room work with broad payload envelope.
- Stroke 30-120 mm
- Ball-screw drive
- Payload to 210 kg
- Benchtop-scale form factor
Stroke range
30 – 120 mm
Max speed
250 mm/s
Horizontal payload
11 – 210 kg
Drive
Ball screw
Catalog View products
Series
AT
Tilt stage with ±5° to ±10° operating angle and ball-screw drive for fine-adjust alignment under load.
- Tilt range 5° – 10°
- Ball-screw fine-adjust
- Payload 12-44 kg
- Stage-grade accuracy
Operating angle
5° – 10°
Horizontal payload
12 – 44 kg
Drive
Ball screw
Catalog View products
Series
SA...DE
Combined linear-plus-rotational stage with 50° to 280° rotation and 10 to 20 mm linear travel for compact three-degrees-of-freedom positioning.
- 50° – 280° rotation
- 10-20 mm linear travel
- Speed to 800 mm/s
- Three degrees of freedom
Rotation range
50° – 280°
Linear stroke
10 – 20 mm
Max speed
800 mm/s
Horizontal payload
2.4 – 30 kg
Catalog View products
Series
SK...W
Continuous-rotation worm gear-driven indexing stage — a single-axis rotational stage classified in the ball-screw family.
- 360° continuous rotation
- Ball-screw indexing
- Compact form factor
Operating angle
360°
Drive
Worm gear
Max payload
5 kg
Catalog View products
Series
TSLB
Timing-belt-driven long-travel positioning stage with strokes up to 1.2 meters for high-speed transport and pick-and-place applications.
- Timing-belt drive
- Stroke 600-1,200 mm
- Speed 1,500 mm/s
- Payload 5-62 kg
Stroke range
600 – 1,200 mm
Max speed
1,500 mm/s
Horizontal payload
5 – 62 kg
Drive
Timing belt
Catalog View products
Series
TZ
Heavy-payload short-stroke ball-screw stage — 109 to 160 kg carry capacity in a 10 to 24 mm stroke envelope.
- Heavy payload (109-160 kg)
- Short stroke 10-24 mm
- Ball-screw drive
- Compact heavy-duty
Stroke range
10 – 24 mm
Max speed
125 mm/s
Horizontal payload
109 – 160 kg
Drive
Ball screw
Catalog View products
