Crossed Roller Bearings

One race, every load direction

Crossed roller bearings arrange cylindrical rollers in alternating 90-degree orientation between inner and outer rings. The result is a single bearing that handles radial loads, axial loads in both directions, and tilting moments at the same time. That combination lets designers shrink the rotary envelope on machine tool tables, robot pivots, medical scanners, and semiconductor handlers without giving up rigidity.

All loads on one race. Alternating roller orientation supports radial, axial, and moment loads in a single bearing, so two-bearing arrangements can collapse into one.
Standard, slim, and super-slim profiles. Section heights from 5 mm slim profiles up to 150 mm full-section bearings cover thin-table robotics through heavy machine tool spindles.
Mounting-hole variants ready to bolt up. Mounting-holed CRBFV and CRBTF variants drop directly into housing plates without separate clamping rings or adapter flanges.

Series

Series
CRB
Standard full-complement crossed roller bearing in high carbon steel, sized from 30 to 800 mm bore for general rotary tables and indexing axes.
- Full complement
- High carbon steel
- Open, one side sealed type or sealed type
Bore range
30 to 800 mm
OD range
55 to 1,030 mm
Max dynamic load
1,980 kN
Catalog View products
Series
CRBC
Standard crossed roller bearing with a steel cage retainer, lower friction at speed than full-complement CRB while keeping the same envelope.
- Steel cage
- Lower friction
- Open, one side sealed type or sealed type
Bore range
30 to 800 mm
OD range
55 to 1,030 mm
Max dynamic load
1,660 kN
Catalog View products
Series
CRBFV
High-rigidity crossed roller bearing with multiple mounting options available including same direction, opposite direction and tapped holes.
- Multiple mounting options
- POM separator
- Open or sealed
Bore range
10 - 115 mm
OD range
52 - 240 mm
Max dynamic load
84 kN
Catalog View products
Series
CRBHV
High-rigidity crossed roller bearing with a POM plastic separator, balancing stiffness and quiet running for precision indexing tables.
- High rigidity
- POM separator
- Open or sealed type
Bore range
20 - 300 mm
OD range
36 - 360 mm
Max dynamic load
112 kN
Catalog View products
Series
CRBS
Slim crossed roller bearing in a low 8 to 13 mm section height, for robot joints and rotary actuators where axial space is tight.
- Slim profile
- POM separator or full complement or cage
- Open for cage type
- One-side-seal and sealed for POM separator type
- Open, one-side seal, and sealed for full-compliment type
Bore range
50 to 200 mm
OD range
66 to 226 mm
Max Dynamic Load
30 kN
Catalog View products
Series
CRBT
Super-slim crossed roller bearing at a 5 mm section height, for ultra-thin rotary stages, optical mounts, and compact robotic wrists.
- Super slim
- POM separator
- Small clearance
Bore range
10 to 50 mm
OD range
21 to 61 mm
Max Dynamic Load
2.28 kN
Catalog View products
Series
CRBTF
Super-slim crossed roller bearing with mounting holes, combining a 5 mm section with direct bolt-down for the thinnest precision rotary axes.
- Super slim
- Mounting holes
- POM separator
Bore range
10 to 40 mm
OD range
43 to 73 mm
Max Dynamic Load
2.44 kN
Catalog View products

One race, every load direction
