Rotary Motion

Machined Type Needle Roller Bearings

Compact, high-capacity rotary support for transmissions, gearboxes, and connecting-rod assemblies where radial space is tight.

High load in a thin section

Needle roller bearings use long, small-diameter rollers to carry heavy radial loads in a cross section a fraction the height of a comparable ball bearing. Machined-ring, separable-cage, and shell-type drawn-cup designs cover everything from automotive gear shafts and pump rotors to industrial reducers and connecting-rod ends. With dynamic load ratings up to 1,910 kN and bores from 5 mm to 490 mm, the family scales from miniature linkages to heavy-machinery shafts.

Thin-section load capacity. Long needle rollers carry full radial load in roughly half the cross section of a ball bearing, freeing shaft and housing space.
Machined, caged, or shell-type. Machined rings for high precision, separable cages with inner rings for ease of assembly, and drawn-cup shells for lightweight, press-fit installations.
Sealed and lubricated options. Two-seal variants exclude contamination in dirty environments, oil-hole versions distribute lubricant under load, and C-Lube solid-lubricant types run maintenance-free.

Series

Series
BR
Inch-dimensioned machined-type needle roller bearing with oil hole, sized for replacement and retrofit on imperial shafts. Open type as standard with optional two-sided seal variant.
- Inch dimensions
- Oil hole
- Two-sided seal option
Bore range
0.625 – 4.00 in
OD range
1.125 – 5.00 in
Max dynamic load
176 kN
Catalog View products
Series
GTR
Double-row, full-complement machined-type needle roller bearing for heavy radial loads in a compact section. No cage, oil-hole lubrication.
- Double row
- Full complement
- Oil hole
Bore range
20 – 150 mm
OD range
33 – 188 mm
Max dynamic load
423 kN
Catalog View products
Series
NA48
Large-bore machined-type needle roller bearing supplied with inner ring and oil hole, sized for heavy industrial shafts from 110 to 380 mm.
- Large bore
- Inner ring included
- Oil hole
Bore range
110 – 380 mm
OD range
140 – 480 mm
Max dynamic load
951 kN
Catalog View products
Series
NA49
Broadest machined-type needle roller bearing range with inner ring and oil hole, covering bores from 5 to 440 mm. Open type, one side seal. Two side seals are available as an option.
- Inner ring included
- Oil hole
- Optional 2 side seals
Bore range
5 – 440 mm
OD range
13 – 600 mm
Max dynamic load
1,910 kN
Catalog View products
Series
NA69
Wide-section machined-type needle roller bearing with inner ring and oil hole, with overall widths from 22 to 63 mm for higher load capacity. Open type, one side seal with two side seals as option.
- Wide section
- Inner ring included
- Optional 2 seals
Bore range
12 – 95 mm
OD range
24 – 130 mm
Max dynamic load
182 kN
Catalog View products
Series
NAF
Separable-cage needle roller bearing supplied with inner ring, sized for assemblies that need easy installation on a shaft journal.
- Separable cage
- Inner ring included
- Single row
Bore range
6 – 90 mm
OD range
17 – 120 mm
Max dynamic load
72 kN
Catalog View products
Series
NAFW
Double-row separable-cage needle roller bearing with inner ring and oil hole, for higher radial capacity in a single assembled unit.
- Separable cage
- Double row
- Inner ring included
Bore range
10 – 70 mm
OD range
22 – 100 mm
Max dynamic load
111 kN
Catalog View products
Series
RNA48
Large-bore machined-type caged needle roller bearing without inner ring. Runs directly on a hardened shaft for maximum radial capacity.
- Large bore
- No inner ring
- Oil hole
Bore range
120 – 415 mm
OD range
140 – 480 mm
Max dynamic load
951 kN
Catalog View products
Series
RNA49
Broadest machined-type caged needle roller bearing range without inner ring, covering bores from 5 to 490 mm. Runs on hardened shaft. Open type, one side seal, two side seals available as an option.
- No inner ring
- Oil hole
- Optional 2 side seals
Bore range
5 – 490 mm
OD range
11 – 600 mm
Max dynamic load
1,910 kN
Catalog View products
Series
RNA69
Wide-section machined-type needle roller bearing without inner ring, double row, with overall widths from 22 to 63 mm for high capacity. Open type, one side seal, and two side seals as an option.
- Double row
- No inner ring
- Optional 2 side seals
Bore range
16 – 110 mm
OD range
24 – 130 mm
Max dynamic load
182 kN
Catalog View products
Series
RNAF
Separable-cage needle roller bearing without inner ring, single row, for compact assemblies that run directly on a hardened shaft journal.
- Separable cage
- No inner ring
- Single row
Bore range
5 – 100 mm
OD range
10 – 120 mm
Max dynamic load
72 kN
Catalog View products
Series
RNAFW
Double-row separable-cage needle roller bearing without inner ring, with oil hole, for higher radial capacity directly on a hardened shaft.
- Separable cage
- Double row
- No inner ring
Bore range
8 – 80 mm
OD range
16 – 100 mm
Max dynamic load
111 kN
Catalog View products
Series
TAF
Compact machined-type needle roller bearing without inner ring, runs on hardened shaft. Available with C-Lube solid lubricant for maintenance-free operation.
- No inner ring
- C-Lube option
- Single row
Bore range
5 – 110 mm
OD range
10 – 130 mm
Max dynamic load
134 kN
Catalog View products
Series
TAFI
Compact machined-type needle roller bearing supplied with inner ring, optional oil hole, sized for small to mid-range shafts from 5 to 100 mm.
- Inner ring included
- Oil hole option
- Single row
Bore range
5 – 100 mm
OD range
15 – 130 mm
Max dynamic load
134 kN
Catalog View products
Series
TAW
Double-row caged shell-type needle roller bearing in chromium molybdenum steel, press-fit drawn cup for connecting-rod and pin-joint duty.
- Shell type
- Double row
- Chromium-moly steel
Bore range
38 – 70 mm
OD range
48 – 82 mm
Max dynamic load
105 kN
Catalog View products
Series
TR
Single-row machined-type needle roller bearing with steel cage and oil hole, the single-row counterpart to the double-row GTR design.
- Single row
- Steel cage
- Oil hole
Bore range
20 – 150 mm
OD range
33 – 188 mm
Max dynamic load
320 kN
Catalog View products
